CBR test machine | cbr test machine diagram-cbr test procedure and calculation, cbr test apparatus Description CBR test machine : cbr testing machine specification, Test Speed Range mm/min 0.5- 5 , Max Horizontal Clearance (mm) 260, Max Vertical Clearance(mm) 690, Min Vertical Clearance (mm)260, You can use as – cbr test procedure, California Bearing Ratio Test on Subgrade Soil, Soil CBR Test – Equipment, Procedure, Calculation & Use, California Bearing Ratio Test and California Bearing Ratio Test. We imports Digital and Analog CBR Test Apparatus also manufacturing tougher product. We are Digital and Analog CBR Test Apparatus, Wholesale cbr test machine To Test Electronic Equipment. CBR Testing machine Best Supplier in Bangladesh .Digital CBR tester BD Details…. The UTS-0856.ACPR Automatic CBR Test Machine is designed for performing laboratory evaluation of the CBR value of highway sub-bases and sub-grade, and determination of the strength of cohesive materials which have maximum particle sizes less than 19 mm (3/4”). The UTS-0856.ACPR is composed of a robust and compact two column frame with adjustable upper crossbeam driven by an electromechanical ram with a maximum capacity of 50 kN and a data acquisition and processing system. The UTS-0856.ACPR is designed to load the penetration piston into the soil sample at a constant rate to measure the applied load and piston penetration at predetermined intervals. This main feature allows the user to perform tests complying to BS, EN, ASTM or AASHTO standards with the same machine. Rapid adjustment of the platen is also provided by up and down buttons which are located on the front panel of the machine. The UTS-0856.ACPR is supplied complete with a 50 kN load cell, penetration piston, linear potentiometric displacement transducer (25 mm x 0.001 mm). U-Touch PRO Control Unit U-Touch PRO Control Unit is designed to control CBR test machine UTS-0856ACPR to perform acc. to EN,ASTM/AASHTO and BS standards. The Unit can perform CBR tests as a stand-alone without the use of a PC or with the USOFT-0856 software and a PC. Control of machine, acquisition of load and displacement data in real time are provided by the unit The control unit has easy to use menu options. It displays all menu option listings simultaneously, allowing the operator to access the required option in a seemless manner to activate the option or enter a numeric value to set the test parameters and see all the data while the test running. Control Unit offers many addition unique features. You can save test results in its internal memory and can be controlled remotely from anywhere around the world. Main Features Can make the test with displacement control Real time display of test graph. 4 analog channels for load cell and displacement sensors Can control second frame Calibration function for channels. Programmable digital gain adjustment for load-cell and potentiometric sensors, voltage and current transmitters Closed-loop PID for steady pace rate Calculates corrected CBR value at 2.5 and 5 mm the digital unit saves the load value at user defined displacement values such as 0.625, 1.25, 1.875, 2.5, 3.75, 5, 7.5,10, 12.5 mm The load corresponds to the displacements corrected respect to the linear region of the data has also saved The % CBR at 2.5 mm and % CBR at 5 mm is also automatically calculated and saved. PLEASE see the pages of “General/Data Aqusition and Control Units” for details of the properties of software and hardware of U-Touch PRO Control Unit RTC online is Bangladeshi Importer, dealer, Supplier and online seller Contact : 01831016720
